RESISTOR AL CLAD 10W 15R 5%; Resistance:15ohm; Product Range:THS Series; Power Rating:10W; Resistance Tolerance:?5%; Resistor Terminals:Solder Lug; Voltage Rating:160V; Resistor Element Material:Wirewound; Temperature Coefficient:?50ppm/蚓; Body Length:17mm; External Length / Height:9mm; External Width:17mm; Fixing Hole Diameter:2.4mm; Full Power Rating Temperature:25蚓; Insulation Resistance:10000Mohm; Lead Length:7mm; Length:30mm; No. of Pins:2Pins; Operating Temperature Max:165蚓; Operating Temperature Min:-25蚓; Operating Temperature Range:-25蚓 to +165蚓; Resistor Case Style:Axial Leaded; Resistor Mounting:Through Hole; Temperature Coeff. +:50ppm/蚓; Temperature Coeff. -:50ppm/蚓; Tolerance +:5%; Tolerance -:5%; Voltage Rating V DC:160V; Voltage Rating VAC:160V; Working Voltage:160V
